IKO Lm guides LWH , LRX , LRXG, LRXD, LWL , LWHD, LWHS , ready Stock available.
C sleeve ways (Maintenance Free)
C sleeve ways (Maintenance Free)
IKO C-Sleeve Way H is a high rigidity type motion rolling guide incorporating built in lubricating parts, C-Sleeves, in Way H. Long term maintenance free can be achieved. The lubricant in C-Sleeve keeps the lubrication performance for a long period of time, so that the man-hours for troublesome re-lubrication control can be reduced and maintenance free operation (5 years or 20, 000 km whichever comes earlier) can be achieved ,
Series: ME , MET (Light) MH , MHD (Heavy Series)
Sizes available: 10 mm to 100 mm
Send Query
Ways E (Compact type)
Ways E (Compact type)
Way E is a motion Rolling guide, featuring a compact slide unit which performs endless motion along a track rail. Two rows of steel ball are arranged in four point contact with the raceways. This design ensures stable high accuracy and rigidity in operations even under fluctuating loads with changing directions and magnitude or complex loads. Way E includes interchangeable specification products. The dimensionof slide units and track rails of this specification are individually controlled, so that units and track rails can be combined added or exchanged freely. They are available both in Flange type and Block type. Also available in Stainless steel.
Sizes available Rail width: 15 mm to 45 mm
Series: LWE (Flanged) , LWEC LWESC (Block type )
Rails available as per required lenght.
Send Query
Ways L (Standard type)
Ways L (Standard type)
Way L is a miniature type motion Rolling guide incorporating two rows of steel ball are arranged in four point contact with the raceways. Although it is small in size, it provides stable accuracy and rigidity owing to its simple design even in operations under fluctuating loads with changing direction and magnitude or complex loads.The standard products are made from stainless steel and a wide range of variations in shapes and sizes are available for selections suitable for each applications, Available in Standard and Wide rail type.
Sizes available Rail width: 3 mm to 42 mm
Series: LWL (standrad) , LWLC (compact) LWLG (high Rigidity long)
Wide Rail type: LWLFC , LWLF , LWLFG
Send Query
Ways H (High Rigidity Type)
Ways H (High Rigidity Type)
Way H incorporates two rows of large diameter steel balls in four point contact with the raceways and provides stable high accuracy and rigidity in operations even under fluctutating loads with changing direction and magnitude or complex loads, . This series features the largest load ratings and rigidity among all ball types. A wide range of variations in shapes and sizes are available for selecting a model suitable for each application. Available in Flanged type and Block type also in Stainless steel.
Sizes available Rail width: 15 mm to 85 mm
Series: LWH (Flanged type) , LWHG (high rigidity), LWHT , LWHD (Block type) LWHS (compact block type), LWHY (Side mounting Y Axis).
Send Query
Ways F (Wide Rail Type)
Ways F (Wide Rail Type)
Way F is a motion rolling guide , featureing a wide track rail along which a highly rigid slide unit performs endless motion. Two rows of large diameter steel balls in four point contact with the raceways and provides stable high accuracy and rigidity in operations even under fluctutating loads with changing direction and magnitude or complex loads. Being wide rail type it can support a large moment load acting around the axial direction, and it is also suitable for single row rail arrangement.
Sizes Available Rail Width: 33 mm, 37mm , 40mm, 42mm, 60mm , 90 mm
